JavaScript/TypeScript SDK

The foc-engine JavaScript/TypeScript SDK provides a comprehensive client library for interacting with foc.fun applications from JavaScript and TypeScript environments.

Installation

Install the SDK using your preferred package manager:

# npm
npm install foc-engine

# yarn
yarn add foc-engine

# pnpm
pnpm add foc-engine

Quick Start

import { FocEngine } from 'foc-engine';

// Initialize the engine
const engine = new FocEngine({
  url: 'http://localhost:8080',
  modules: ['registry', 'accounts', 'events', 'paymaster']
});

// Connect to the engine
await engine.connect();

// Start using modules
const registry = engine.getModule('registry');
const accounts = engine.getModule('accounts');

Configuration

Basic Configuration

const engine = new FocEngine({
  url: 'http://localhost:8080',     // Engine URL
  wsUrl: 'ws://localhost:8081',      // WebSocket URL for events
  timeout: 30000,                    // Request timeout (ms)
  retries: 3,                        // Retry failed requests
  modules: ['registry', 'accounts'], // Modules to load

  // Paymaster configuration with AVNU fallback
  paymaster: {
    primary: {
      type: 'foc-engine',
      endpoint: 'https://api.foc.fun/paymaster/sepolia'
    },
    fallback: {
      type: 'avnu',
      apiKey: process.env.AVNU_API_KEY // AVNU API key for fallback
    }
  }
});

Advanced Configuration

const engine = new FocEngine({
  url: 'http://localhost:8080',
  wsUrl: 'ws://localhost:8081',

  // Request configuration
  timeout: 30000,
  retries: 3,
  retryDelay: 1000,

  // Module configuration
  modules: {
    registry: {
      cache: true,
      cacheTimeout: 300000  // 5 minutes
    },
    accounts: {
      autoConnect: true,
      defaultImplementation: 'openzeppelin'
    },
    events: {
      reconnect: true,
      reconnectDelay: 5000,
      maxReconnectAttempts: 10
    },
    paymaster: {
      enabled: true,
      // AVNU fallback configuration
      fallback: {
        provider: 'avnu',
        apiKey: process.env.AVNU_API_KEY,
        endpoint: 'https://paymaster.avnu.fi',
        timeout: 10000,
        retries: 3
      }
    }
  },

  // Network configuration
  network: 'devnet',  // 'devnet', 'testnet', 'mainnet'

  // Logging
  debug: true,
  logger: console
});

Core API

Engine Methods

connect()

Connect to the foc-engine:

await engine.connect();

// With connection options
await engine.connect({
  timeout: 10000,
  retries: 5
});

disconnect()

Disconnect from the engine:

await engine.disconnect();

getModule(name)

Get a module instance:

const registry = engine.getModule('registry');
const accounts = engine.getModule('accounts');
const events = engine.getModule('events');
const paymaster = engine.getModule('paymaster');

isConnected()

Check connection status:

if (engine.isConnected()) {
  console.log('Engine is connected');
}

getStatus()

Get engine status:

const status = await engine.getStatus();
console.log(status);
// {
//   connected: true,
//   version: '1.0.0',
//   modules: ['registry', 'accounts', 'events', 'paymaster'],
//   network: 'devnet',
//   blockNumber: 12345
// }

Contract Interaction

Deploying Contracts

// Deploy a contract
const contract = await engine.deploy({
  contract: 'MyToken',  // Contract name or path
  constructorArgs: {
    name: 'My Token',
    symbol: 'MTK',
    decimals: 18,
    totalSupply: '1000000000000000000000'
  }
});

console.log('Deployed at:', contract.address);

Contract Class

Work with deployed contracts:

// Get contract instance
const token = await engine.getContract('0x123...');

// Or from registry
const registry = engine.getModule('registry');
const token = await registry.getContract('MyToken');

// Call read function
const balance = await token.call('balanceOf', {
  account: '0x456...'
});

// Send transaction
const tx = await token.invoke('transfer', {
  to: '0x789...',
  amount: '1000000000000000000'
});

// Wait for confirmation
await tx.wait();
console.log('Transaction confirmed:', tx.hash);

Transaction Options

// With custom options
const tx = await token.invoke('transfer', {
  to: '0x789...',
  amount: '1000'
}, {
  account: '0xmyaccount...',     // Specific account to use
  maxFee: '1000000000000000',    // Max fee in wei
  nonce: 5,                       // Custom nonce
  paymaster: true,                // Use paymaster (with AVNU fallback)
  waitForAccept: true             // Wait for L2 acceptance
});

// Force specific paymaster provider
const txWithAvnu = await token.invoke('transfer', {
  to: '0x789...',
  amount: '1000'
}, {
  account: '0xmyaccount...',
  paymaster: {
    provider: 'avnu',             // Force AVNU paymaster
    apiKey: process.env.AVNU_API_KEY
  }
});

Multicall

Execute multiple calls in one transaction:

// Prepare calls
const calls = [
  token.populateTransaction('approve', {
    spender: '0xdex...',
    amount: '1000000'
  }),
  dex.populateTransaction('swap', {
    tokenIn: token.address,
    tokenOut: '0xother...',
    amountIn: '1000000'
  })
];

// Execute multicall
const tx = await engine.multicall(calls);
await tx.wait();

Type Safety with TypeScript

Basic Types

import { FocEngine, Contract, Transaction } from 'foc-engine';

const engine: FocEngine = new FocEngine({
  url: 'http://localhost:8080'
});

const contract: Contract = await engine.getContract('0x123...');
const tx: Transaction = await contract.invoke('transfer', {
  to: '0x456...',
  amount: '1000'
});

Generated Types

Generate TypeScript types from your contracts:

# Generate types
foc-engine generate-types --output ./types

Use generated types:

import { MyToken } from './types/MyToken';

const token = await engine.getContract<MyToken>('0x123...');

// Type-safe calls
const balance = await token.balanceOf({ account: '0x456...' });
const tx = await token.transfer({
  to: '0x789...',
  amount: BigInt('1000000000000000000')
});

Module Types

import {
  Registry,
  Accounts,
  Events,
  Paymaster
} from 'foc-engine';

const registry: Registry = engine.getModule('registry');
const accounts: Accounts = engine.getModule('accounts');
const events: Events = engine.getModule('events');
const paymaster: Paymaster = engine.getModule('paymaster');

Event Handling

Basic Event Subscription

const events = engine.getModule('events');

// Subscribe to events
const subscription = await events.subscribe({
  contract: '0xtoken...',
  event: 'Transfer',
  callback: (event) => {
    console.log(`Transfer: ${event.from} -> ${event.to}`);
  }
});

// Unsubscribe later
subscription.unsubscribe();

Event Emitter Pattern

// Get event emitter
const emitter = await token.events();

// Listen to specific event
emitter.on('Transfer', (from, to, amount) => {
  console.log(`Transfer: ${from} -> ${to}: ${amount}`);
});

// Listen to all events
emitter.on('*', (eventName, ...args) => {
  console.log(`Event ${eventName}:`, args);
});

// Remove listeners
emitter.off('Transfer', handler);
emitter.removeAllListeners();

Paymaster Integration

AVNU Fallback Configuration

// Configure automatic AVNU fallback
const engine = new FocEngine({
  network: 'sepolia',
  paymaster: {
    // Primary: FOC Engine paymaster
    primary: {
      type: 'foc-engine',
      endpoint: 'https://api.foc.fun/paymaster/sepolia'
    },

    // Fallback: AVNU direct integration
    fallback: {
      type: 'avnu',
      apiKey: process.env.AVNU_API_KEY,
      endpoint: 'https://paymaster.avnu.fi',

      // Fallback triggers
      triggers: {
        timeout: 10000,
        retries: 3,
        errorCodes: ['503', '504', 'TIMEOUT']
      }
    },

    // Fallback behavior
    fallbackOnError: true,
    logFallbacks: true
  }
});

Direct AVNU Integration

// Use AVNU paymaster only (no FOC Engine fallback needed)
const engine = new FocEngine({
  network: 'sepolia',
  paymaster: {
    type: 'avnu-only',
    apiKey: process.env.AVNU_API_KEY,
    endpoint: 'https://paymaster.avnu.fi',

    // AVNU-specific options
    options: {
      maxFeePercentage: 10,  // Max 10% of transaction value as fee
      validityPeriod: 3600,  // 1 hour validity
      gaslessTokens: ['ETH', 'USDC', 'USDT']
    }
  }
});

// All transactions will use AVNU paymaster
const paymaster = engine.getModule('paymaster');
const sponsoredTx = await paymaster.sponsor({
  account: '0xuser...',
  to: '0xcontract...',
  selector: 'transfer',
  calldata: ['0xrecipient...', '1000']
});

Paymaster Event Handling

// Monitor paymaster fallback events
engine.paymaster.on('fallbackTriggered', (event) => {
  console.log('Paymaster fallback:', {
    reason: event.reason,
    primaryProvider: event.primary,
    fallbackProvider: event.fallback,
    transactionHash: event.txHash
  });
});

// Track paymaster provider health
engine.paymaster.on('providerHealthChange', (event) => {
  console.log('Provider health:', {
    provider: event.provider,
    status: event.status, // 'healthy', 'degraded', 'down'
    latency: event.latency,
    successRate: event.successRate
  });
});

Error Handling

Error Types

import {
  FocEngineError,
  ConnectionError,
  ContractError,
  TransactionError,
  ModuleError,
  PaymasterError
} from 'foc-engine';

try {
  await engine.connect();
} catch (error) {
  if (error instanceof ConnectionError) {
    console.error('Failed to connect:', error.message);
  } else if (error instanceof ModuleError) {
    console.error('Module error:', error.module, error.message);
  } else if (error instanceof PaymasterError) {
    console.error('Paymaster error:', error.provider, error.message);
  }
}

Transaction Errors with Paymaster Fallback

try {
  const tx = await token.invoke('transfer', {
    to: '0x789...',
    amount: '1000000'
  }, {
    paymaster: true // Enables automatic AVNU fallback
  });
  await tx.wait();
} catch (error) {
  if (error instanceof TransactionError) {
    switch (error.code) {
      case 'INSUFFICIENT_BALANCE':
        console.error('Not enough tokens');
        break;
      case 'REVERTED':
        console.error('Transaction reverted:', error.reason);
        break;
      case 'TIMEOUT':
        console.error('Transaction timed out');
        break;
      case 'PAYMASTER_UNAVAILABLE':
        console.error('All paymasters failed:', error.providers);
        break;
    }
  } else if (error instanceof PaymasterError) {
    if (error.fallbackUsed) {
      console.log('Transaction succeeded using AVNU fallback');
    } else {
      console.error('Paymaster failed:', error.message);
    }
  }
}

Utilities

Address Utilities

import { utils } from 'foc-engine';

// Validate address
if (utils.isValidAddress('0x123...')) {
  console.log('Valid address');
}

// Format address
const formatted = utils.formatAddress('0x123...');

// Get address from public key
const address = utils.getAddressFromPublicKey('0xpubkey...');

Number Utilities

// Convert between units
const wei = utils.parseEther('1.5');  // 1.5 ETH to wei
const eth = utils.formatEther('1500000000000000000');  // wei to ETH

// BigInt utilities
const sum = utils.addBigInt('1000', '2000');
const product = utils.multiplyBigInt('1000', '2');

Encoding Utilities

// Encode function call
const calldata = utils.encodeCall('transfer', {
  to: '0x789...',
  amount: '1000'
});

// Decode event
const decoded = utils.decodeEvent('Transfer', eventData);

React Integration

Provider Component with AVNU Fallback

import { FocEngineProvider } from 'foc-engine/react';

function App() {
  return (
    <FocEngineProvider
      config={{
        url: 'http://localhost:8080',
        modules: ['registry', 'accounts', 'events', 'paymaster'],

        // AVNU fallback configuration
        paymaster: {
          primary: {
            type: 'foc-engine',
            endpoint: process.env.REACT_APP_FOC_PAYMASTER_URL
          },
          fallback: {
            type: 'avnu',
            apiKey: process.env.REACT_APP_AVNU_API_KEY
          },
          fallbackOnError: true
        }
      }}
    >
      <YourApp />
    </FocEngineProvider>
  );
}

Hooks with Paymaster

import {
  useFocEngine,
  useContract,
  useAccount,
  useEvents,
  usePaymaster
} from 'foc-engine/react';

function TokenTransfer({ tokenAddress }) {
  const engine = useFocEngine();
  const token = useContract(tokenAddress);
  const paymaster = usePaymaster();
  const [isTransferring, setIsTransferring] = useState(false);

  const transfer = async (to, amount) => {
    setIsTransferring(true);
    try {
      // Automatically uses AVNU fallback if FOC paymaster fails
      const tx = await token.invoke('transfer', { to, amount }, {
        paymaster: true
      });
      await tx.wait();
      console.log('Transfer successful');
    } catch (error) {
      console.error('Transfer failed:', error);
    } finally {
      setIsTransferring(false);
    }
  };

  return (
    <div>
      <button
        onClick={() => transfer('0x123...', '1000')}
        disabled={isTransferring}
      >
        {isTransferring ? 'Transferring...' : 'Send Gasless Transfer'}
      </button>

      {/* Show paymaster status */}
      <div>Paymaster Status: {paymaster.status}</div>
      {paymaster.fallbackActive && (
        <div>Using AVNU fallback</div>
      )}
    </div>
  );
}

Testing

Mock Engine

import { MockEngine } from 'foc-engine/testing';

describe('MyComponent', () => {
  let mockEngine;

  beforeEach(() => {
    mockEngine = new MockEngine();
    mockEngine.mockContract('0xtoken...', {
      balanceOf: async ({ account }) => '1000000',
      transfer: async ({ to, amount }) => ({
        hash: '0xmocktx...',
        wait: async () => ({ status: 'success' })
      })
    });
  });

  test('should transfer tokens', async () => {
    const token = await mockEngine.getContract('0xtoken...');
    const tx = await token.invoke('transfer', {
      to: '0x789...',
      amount: '1000'
    });
    expect(tx.hash).toBe('0xmocktx...');
  });
});

Test Utilities

import { testUtils } from 'foc-engine/testing';

// Create test accounts
const accounts = await testUtils.createTestAccounts(5);

// Fund accounts
await testUtils.fundAccounts(accounts, '1000000000000000000');

// Deploy test token
const token = await testUtils.deployTestToken({
  name: 'Test Token',
  symbol: 'TEST',
  supply: '1000000'
});

Performance

Connection Pooling

const engine = new FocEngine({
  url: 'http://localhost:8080',
  pool: {
    min: 2,
    max: 10,
    idleTimeout: 30000
  }
});

Caching

// Enable caching
const engine = new FocEngine({
  cache: {
    enabled: true,
    ttl: 300000,  // 5 minutes
    max: 1000     // Max cached items
  }
});

// Cache specific calls
const balance = await token.call('balanceOf', {
  account: '0x456...'
}, {
  cache: true,
  cacheKey: `balance-${account}`,
  cacheTTL: 60000  // 1 minute
});

Batch Requests

// Batch multiple calls
const results = await engine.batch([
  token.populateCall('balanceOf', { account: '0x123...' }),
  token.populateCall('balanceOf', { account: '0x456...' }),
  token.populateCall('totalSupply')
]);

console.log(results);  // [balance1, balance2, totalSupply]

Migration Guide

From Web3.js

// Web3.js
const balance = await token.methods.balanceOf(account).call();
await token.methods.transfer(to, amount).send({ from: account });

// foc-engine
const balance = await token.call('balanceOf', { account });
await token.invoke('transfer', { to, amount }, { account });

From Ethers.js

// Ethers.js
const balance = await token.balanceOf(account);
const tx = await token.transfer(to, amount);
await tx.wait();

// foc-engine
const balance = await token.call('balanceOf', { account });
const tx = await token.invoke('transfer', { to, amount });
await tx.wait();

Best Practices

1. Resource Management

Always clean up resources:

const engine = new FocEngine({ /* config */ });

try {
  await engine.connect();
  // Use engine
} finally {
  await engine.disconnect();
}

2. Error Handling

Implement comprehensive error handling:

async function safeTransfer(token, to, amount) {
  try {
    const tx = await token.invoke('transfer', { to, amount });
    return await tx.wait();
  } catch (error) {
    if (error.code === 'INSUFFICIENT_BALANCE') {
      throw new Error('Not enough tokens');
    }
    throw error;
  }
}

3. Type Safety

Use TypeScript for better development experience:

interface TokenTransferParams {
  to: string;
  amount: bigint;
}

async function transfer(
  token: Contract,
  params: TokenTransferParams
): Promise<Transaction> {
  return token.invoke('transfer', params);
}

Troubleshooting

Connection Issues

// Enable debug logging
const engine = new FocEngine({
  url: 'http://localhost:8080',
  debug: true
});

// Listen to connection events
engine.on('connected', () => console.log('Connected'));
engine.on('disconnected', () => console.log('Disconnected'));
engine.on('error', (error) => console.error('Error:', error));

Performance Issues

// Monitor performance
const metrics = await engine.getMetrics();
console.log({
  requestsPerSecond: metrics.rps,
  averageLatency: metrics.avgLatency,
  activeConnections: metrics.connections
});

Source Code

Main SDK Repository: foc-engine.js
Core SDK Implementation: foc-engine.js/src/core
Module Implementations: foc-engine.js/src/modules

TypeScript Types

Type Definitions: foc-engine.js/src/types
Generated Contract Types: foc-engine.js/types

React Integration

React Hooks: foc-engine.js/src/react
Provider Components: foc-engine.js/src/react/providers

Examples & Templates

SDK Examples: foc-engine.js/examples
Integration Examples: foc-fun/examples
Sample Applications: foc-examples

Testing & Development

Test Suite: foc-engine.js/tests
Mock Utilities: foc-engine.js/src/testing
Development Tools: foc-engine.js/tools

Build & Configuration

Build Scripts: foc-engine.js/scripts
Configuration Files: foc-engine.js/config

Next Steps

Explore the Getting Started guide
Learn about Modules
Check out example applications

Installation​

Quick Start​

Configuration​

Basic Configuration​

Advanced Configuration​

Core API​

Engine Methods​

connect()​

disconnect()​

getModule(name)​

isConnected()​

getStatus()​

Contract Interaction​

Deploying Contracts​

Contract Class​

Transaction Options​

Multicall​

Type Safety with TypeScript​

Basic Types​

Generated Types​

Module Types​

Event Handling​

Basic Event Subscription​

Event Emitter Pattern​

Paymaster Integration​

AVNU Fallback Configuration​

Direct AVNU Integration​

Paymaster Event Handling​

Error Handling​

Error Types​

Transaction Errors with Paymaster Fallback​

Utilities​

Address Utilities​

Number Utilities​

Encoding Utilities​

React Integration​

Provider Component with AVNU Fallback​

Hooks with Paymaster​

Testing​

Mock Engine​

Test Utilities​

Performance​

Connection Pooling​

Caching​

Batch Requests​

Migration Guide​

From Web3.js​

From Ethers.js​

Best Practices​

1. Resource Management​

2. Error Handling​

3. Type Safety​

Troubleshooting​

Connection Issues​

Performance Issues​

Related Code & Resources​

Source Code​

TypeScript Types​

React Integration​

Examples & Templates​

Testing & Development​

Build & Configuration​

Next Steps​

Installation

Quick Start

Configuration

Basic Configuration

Advanced Configuration

Core API

Engine Methods

connect()

disconnect()

getModule(name)

isConnected()

getStatus()

Contract Interaction

Deploying Contracts

Contract Class

Transaction Options

Multicall

Type Safety with TypeScript

Basic Types

Generated Types

Module Types

Event Handling

Basic Event Subscription

Event Emitter Pattern

Paymaster Integration

AVNU Fallback Configuration

Direct AVNU Integration

Paymaster Event Handling

Error Handling

Error Types

Transaction Errors with Paymaster Fallback

Utilities

Address Utilities

Number Utilities

Encoding Utilities

React Integration

Provider Component with AVNU Fallback

Hooks with Paymaster

Testing

Mock Engine

Test Utilities

Performance

Connection Pooling

Caching

Batch Requests

Migration Guide

From Web3.js

From Ethers.js

Best Practices

1. Resource Management

2. Error Handling

3. Type Safety

Troubleshooting

Connection Issues

Performance Issues

Related Code & Resources

Source Code

TypeScript Types

React Integration

Examples & Templates

Testing & Development

Build & Configuration

Next Steps
